ZT Solar power Stand forming machine roll forming machine
Basic Info
Model No.: ZT-009-07
Product Description
ZT Solar power Stand forming machine roll forming machine
ZT Solar power Stand forming machine roll forming machine Profile for your referenced
ZT Solar power Stand forming machine roll forming machine factory introduction
Our factory is professional in rool forming machine for about 20 years.We offer the glazed tile roll forming machine, roof/wall panel roll forming machine, double layer roll forming machine, C & Z purlin machine, floor deck roll forming machine, highway guardrail machine, dust shield machine, ridge cap machine, roll shutter door machine, uncoiling & leveling & slitting & recoiling line, all kinds of decoilers and stackers, and many other related equipments like shear, punch, slitter, leveler, crimping curving, bending and so on.
ZT Solar power Stand forming machine roll forming machine details
The green energy solar power is popular and popular. If you want to collect the solar power, we should have the solarpower stand which can support the solar power. Our machine is making the solar stand .Our solar power stand roll forming machine can be used for many years while producing the high quality solar stand.
ZT Solar power Stand forming machine roll forming machine details:
1. Technique parameters of the processing line
| Main parameters of ZT Solar Stand forming machine | ||
| 1 | Suitable material | galvanizes sheet/ colored coil |
| 4 | Control System | PLC , Inverter Encoder ,Touch Screen etc |
| 5 | PLC/inverter/encoder Brand | Delta, Panasonic, Schneider |
| 6 | Main Power | 15kw |
| 7 | Pump Power | 3kw |
| 8 | Roller Station | 15 stations |
| 9 | Forming Speed | 10-14.8m/min |
| 10 | Backboard Thickness | 18mm |
| 11 | Shaft Diameter | 75 mm |
| 12 | Feeding Thickness | 1.5-2.5mm |
| 13 | Roller material | 45# steel |
| 14 | Cutter Standard | GCr12 |
| 15 | Main forming machine body | 400 mm H steel |
2. Spare parts of the Solar Stand machine
| NO | Name | Unit | Qty |
| 1 | Button | 4 | 4 |
| 2 | Counter | 1 | 1 |
| 3 | Nylon wheel | 2 | 2 |
| 4 | protective tube | 2 | 2 |
| 5 | Limit Switch | 2 | 2 |
| 6 | Pump pipe | 2 | 2 |
Product Categories : C/Z/U Purline Roll Forming Machine > U Bracket Solar Power Stent Manufacturing Series
